Metal DC Geared Motor 6V 20RPM 7.5Kg.cm

This is a metal DC geared motor, 362:1 metal reducer. It has a small size and large torque. The maximum torque could arrive 7.5 kg.cm. It is stable and durable!

SPECIFICATION

• Rated Voltage: 6 V

• Operating Voltage Range 2~7.5V

• Gear reduction ratio: 362:1

• Gearbox length: 27 mm

• "D" shape shaft diameter: 4 mm

• No-load speed: 20 RPM @ 6V

• No-load current: 50 mA

• Locked-rotor torque: 7.5 Kg.cm

• Locked-rotor current: 0.6 A

• Operating Temperature: -20～60℃

• Weight: 74 g


SHIPPING LIST

• Metal DC Geared Motor - 6V 20RPM 7.5Kg.cm x1
