Tamiya 70188 Mini Motor Gearbox 8-Speed Kit


Tamiya’s 8-speed mini motor gearbox features a more compact 030-form-factor brushed DC motor driving a single gear train that can be assembled to have one of eight gear ratios: 7.5:1, 9.5:1, 15.7:1, 19.9:1, 32.9:1, 41.8:1, 79.1:1, or 87.8:1.

Features

  • 030-form-factor motor
    • Speed @ 3 V: 8400 RPM
    • Free-run current @ 3 V: 60 mA
    • Stall current @ 3 V: 600 mA
    • Stall torque @ 3 V: see picture to the right for torque table
  • 8 different gear ratios, which can be adjusted by changing the pinion gear and final gear position
    • 7.5:1
    • 9.5:1
    • 15.7:1
    • 19.9:1
    • 32.9:1
    • 41.8:1
    • 79.1:1
    • 87.8:1
  • 3 mm hexagonal output shaft compatible with our adapter for LEGO wheels and many of Tamiya’s wheels.
  • Mounting holes designed to work with the Tamiya 70098 universal plate set and other Tamiya construction series products.
  • Transparent gear housing shows the internal mechanisms
  • Compact size of approximately 20 x 18 x 50 mm (0.8" x 0.7" x 2")
