Add Infrared Detection to Your Next Project
The Temperature Infrared Thermometer Module is an infrared proximity sensor designed for presence sensing, short-range detection, and touchless automation. It is a practical fit for makers, students, and engineers who want reliable sensor data in embedded builds.
Key details include Measurement Range: -33~220°C / -27~428°F; Operating Range: -10~50°C / 14~122°F; Operating Voltage: 3V or 5V.
Important: Infrared and optical readings change with target color, surface finish, distance, and strong ambient light. Test with your real target before final mounting.
Why you’ll love it
- Sensing range: -33~220°C / -27~428°F
- Power range: 3V or 5V
- Expected accuracy: +/-0.6°C
- Readable detail: 1/16°C=0.0625 (full range)
- Compact size: 12x13.7x35mm(0.47x0.54x1.38")
- Useful spec: 9g
Compare with similar products
| Product | Sensor style | Standout |
|---|---|---|
| Temperature Infrared Thermometer Module | infrared proximity sensor | Current item |
| Thermometer Temperature GY-906-BAA BCC MLX90614 Infrared Temperature Sensor IIC | infrared proximity sensor | infrared sensing, temperature sensing |
| Thermometer Digital Display DS18B20 | temperature sensor with digital output | digital output, temperature sensing |
| Temperature Infrared Sensor Grove | infrared proximity sensor | infrared sensing, temperature sensing |
What you can build
This sensor is a good fit for touchless dispensers, object counters, door triggers, small robots, and presence alarms.
Starter bundles
Pair it with an Arduino-compatible board, ESP32, or Raspberry Pi, plus a breadboard or jumper wires for quick setup and testing.
Recommended add-ons
Useful add-ons include probe mounts, thermal paste if needed, and a data logger, depending on how you plan to power, mount, and log the sensor.
Technical specifications
| Product | Temperature Infrared Thermometer Module |
|---|---|
| Measurement Range | -33~220°C / -27~428°F |
| Operating Range | -10~50°C / 14~122°F |
| Full Range Accuracy #AC | +/-2%, 2°C |
| Operating Voltage | 3V or 5V |
| Accuracy Tobj=15~35°C, Tamb=25°C | +/-0.6°C |
| Resolution | 1/16°C=0.0625 (full range) |
| Size | 12x13.7x35mm(0.47x0.54x1.38") |
| Weight | 9g |
Wiring & usage notes
Check the pin labels on the Temperature Infrared Thermometer Module and match them to your controller voltage, ground, and signal pins. Keep wiring short and verify the logic level before powering the module. Infrared and optical readings change with target color, surface finish, distance, and strong ambient light. Test with your real target before final mounting.
What’s in the box
1 × Temperature Infrared Thermometer Module
Frequently Asked Questions
What does the Temperature Infrared Thermometer Module measure?
It is designed to measure nearby objects, remote IR signals, or motion.
Can I use it with Arduino, ESP32, or Raspberry Pi?
Yes. It is well suited for common maker and embedded platforms, as long as you power it at the correct voltage and match the signal level to your controller.
What affects accuracy?
Power quality, wiring, mounting, target material, and the real environment can all affect the reading. It is best to test and calibrate in the final setup.
Is it good for prototyping?
Yes. It is a practical choice for learning, proof-of-concept builds, and small automation projects.
