Raspberry Pi 3 Model B+
Raspberry Pi 3 Model B+ - Raspberry Pi 3 Model B+ is a new introduction by Raspberry Pi Foundation as an upgraded version of the previous Raspberry Pi 3 Model B. It comes well-packed with tons of advanced features to support your project overwhelmingly. The circuit features an inbuilt metal heatsink, dual-band (2.4GHz-5GHz) wireless LAN, and a separate PoE HAT.
Further, the Raspberry Pi 3 Model B+ is the latest development in the Raspberry Pi 3 lineup. What makes the computer chip compact and powerful is the integration of Broadcom BCM2837, 64-bit Quad-Core Processor, and many other facilities. Further, the Raspberry Pi 3 Model B+ unit integrates 4 inbuilt USB ports to ensure users enjoy flexibility while creating connections. Additionally, it allows you to add more connections using a USB hub.
Why Select Raspberry Pi 3 Model B+?
The Raspberry Pi 3 Model B+ computer is pledged to serve you with superior performance and flexibility. One can expect great speed and powerful connectivity when you decide to incorporate Internet-of-Things or learn computer programming. The unit is efficient to help you conquer your ambitions more reliably.
Furthermore, Raspberry Pi 3 Model B+widens your imagination endlessly by bringing enormous specifications into one place. It can serve you with several facilities such as gaming; work monitoring, productivity, full IoT integration, and lots of other applications.
The Raspberry Pi 3 Model B+ integration captures modular compliance certification in the LAN department. It is dedicatedly designed as an affordable unit for experimentation as well as education in computer learning. It can handle multiple tasks that a normal desktop PC can do. Users are free to entertain spreadsheets, word-processing, and multimedia stuff, including HD videos, games, photos, and programming. Moreover, you can also use external USB devices i.e. mouse, keyboard, and others via USB ports.
The Raspberry Pi 3 Model B+ is a credit card size computer with a staggering 1.4 GHz processing speed in a 64-bit quad-core processor. It also has a 5 GHz wireless LAN, Bluetooth 4.2, and faster Ethernet. The power can be from a micro USB or Power over Ethernet.
The Raspberry Pi 3 Model B+ maintains the same electronic footprint as both the Raspberry Pi 2 Model B and the Raspberry Pi 3 Model B.
Frequently Asked Questions
Q1: How many USB ports are there on the Raspberry Pi 3 Model B?
Similar to its forerunners, it contains a MicroSD card slot, a 3.5mm audio/composite video out connector, four USB2 ports, a full-sized HDMI port, a 10/100 Ethernet port, and other interfaces. The Pi 3 includes 1GB of RAM and the same Broadcom VideoCore IV graphics hardware as the Pi 2.
Q2: Has WiFi been added to the Raspberry PI 3 B+?
The first Raspberry Pi model with built-in WiFi and Bluetooth is the Raspberry Pi 3. The Raspberry Pi Zero W, Raspberry Pi 3 B+, and Raspberry Pi 4 are later models that have these features.How much RAM does a Raspberry Pi 3 B+ have?
The last updated Raspberry Pi 3 Model B+ has a quick speed 64-bit 1.4GHz quad-core processor, 1GB of RAM, dual-band 802.11 b/g/n/ac wireless LAN, Bluetooth 4.2, and rapid speed 300Mbit/s Ethernet.
Q3: In comparison to the Raspberry Pi 3 B+, which should I purchase?
The Broadcom processor in the 3B+ has been revised to be a little bit speedier, but the big advancements are in the networking department. Spend the additional money if you're buying new, but we wouldn't recommend ripping out any model 3B boards that are still in good condition. If you're developing any type of linked project, the 3B+ provides enhancements where it matters. If you don't have a particular requirement, we still advise it over the earlier model despite the significant price increase.
The first Raspberry Pi 3B is still a fairly powerful device. The Plus upgrade consists of certain networking hardware upgrades, such as Gigabit Ethernet, PoE, and a new Dual-band 802.11ac Wi-Fi chip, as well as a new processor specification for which there isn't much of an advantage.
The distinctions here are a little more subtle than they are in the smartphone world, where a plus sign (+) indicates that you should anticipate something bigger. Take a look at the 3 B+'s new features to learn why you should consider using one for your upcoming project rather than just picking up a tried-and-true Raspberry Pi 3 and getting to work on the wiring.
- A 1.4GHz 64-bit quad-core ARM Cortex-A53 CPU
- Dual-band 802.11ac wireless LAN and Bluetooth 4.2
- Faster Ethernet (Gigabit Ethernet over USB 2.0)
- Power-over-Ethernet support (with separate PoE HAT)
- Improved PXE network and USB mass-storage booting
- Improved thermal management
- Processor: Broadcom BCM2837B0, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz
- Memory: 1GB LPDDR2 SDRAM
- Power Supply: 5V/2.5A DC power input (micro-USB)
- Wireless: 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN, Bluetooth 4.2, BLE
- Ethernet: Gigabit Ethernet over USB 2.0 (maximum throughput 300 Mbps)
- GPIOs: Extended 40-pin GPIO header
- Video Output: Full-size HDMI
- Audio Output: 4-pole stereo output and composite video port
- USB Port: 4 USB 2.0 ports
- CSI camera port for connecting a Raspberry Pi camera
- DSI display port for connecting a Raspberry Pi touchscreen display
- Micro SD port for loading your operating system and storing data
- Power-over-Ethernet (PoE) support (requires separate PoE HAT)
- Operating Temperature: 0~50℃Dimension: 120mm x 75mm x 34mm
- Weight: 75g
