Battery 2S 7.4V 13A Charger 18650
Battery 2S 7.4V 13A Charger 18650 - The 2S 7.4V 13A charger is a device designed to charge 18650 batteries. It is a versatile charger that can charge a wide range of devices including power banks, flashlights, and electric bicycles. Understanding how the charger works can help you use it more efficiently and increase the life of your 18650 batteries.To know more about Battery 2S 7.4V 13A Charger 18650, read this blog.
Voltage and Amperage
The charger is designed for 2S 7.4V batteries, which means it can charge two batteries in series with a voltage of 7.4V. The 13A amperage rating indicates the maximum charging current the charger can handle. This means that the charger can charge the batteries at a rate of 13A, which is faster than most chargers.
Charging process
The charging process begins when you plug the charger into an electrical outlet and connect the 18650 batteries to the charger. The charger will then begin to charge the batteries at the maximum amperage rate of 13A until the batteries reach a full charge. The charger will then automatically switch to a lower amperage rate to maintain the charge on the batteries.
Safety features
The charger has several safety features to protect the batteries and the charger from overcharging, over-discharging and short-circuiting. This helps to prolong the life of the batteries and ensure that the charger is safe to use.
Compatibility
The 2S 7.4V 13A charger is a versatile and efficient device for charging 18650 batteries. It can charge two batteries in series with a voltage of 7.4V at a maximum amperage rate of 13A. The charger is also equipped with safety features to protect the batteries and the charger from overcharging, over-discharging and short-circuiting.
The charger is compatible with most 18650 batteries, which are widely used in a variety of devices such as power banks, flashlights, and electric bicycles.
QUICK SPECS:
- Overcharge voltage range: 4.25-4.35v + 0.05v
- Size: 46*20*3.6mm
- Over voltage range: 2.5-3.0v + 0.05v
- Upper operating current: 13A
- Operating temperature: -40---+50 centigrade
- Upper limit instantaneous current: 20A
- Storage condition: -40-- +80 DEG C
- Quiescent current: less than 10uA
- Effective life: more than 50000 hours
- Internal resistance: less than 300m ohm
- Short circuit protection: it can be protected and needs recharging
- Charging voltage: 8.4V-9V
