7-inch Capacitive HDMI Display with Case, Audio, and Broad Device Support

The 7inch Capacitive Touch Screen LCD with Case is a polished display option for Raspberry Pi, Jetson, and PC setups that need a ready-to-use enclosure and a more premium touch experience. It combines a 1024×600 IPS panel with 5-point capacitive touch, a toughened glass cover, and an integrated case.

Because it supports both HDMI and VGA video input, plus USB touch, this model fits clean kiosk builds, desktop dashboards, portable consoles, and demo units. The built-in case also helps it look more finished in retail and client-facing installs.

Important: Official Waveshare docs say multi-touch support depends on the host OS. Raspberry Pi OS and Windows support 5-point touch, while some Linux-based systems are listed as single-point touch.

Why you'll love it

Ready-made case: Cleaner finish for display projects, demos, and enclosures
5-point capacitive touch: More natural touch response than resistive panels
1024×600 IPS panel: Sharp display with wide viewing angles
HDMI and VGA input: More flexible than HDMI-only displays
3.5mm audio output: Passes HDMI audio to headphones or speakers
Jetson and PC support: Useful beyond Raspberry Pi-only builds

Good fit for

This display works well for Ready-to-deploy kiosk and desktop use. It is a practical choice if you want an official Waveshare HDMI screen with clear setup docs and strong compatibility with Raspberry Pi workflows.

Waveshare display lineup comparison

Model	Size	Resolution	Touch	Panel	Interface	Case	Best for
3.5inch HDMI LCD	3.5"	480×320	Resistive (SPI)	IPS	HDMI	No	Small dashboards and handheld use
5inch HDMI LCD	5"	800×480	Resistive (SPI)	TFT	HDMI	No	Budget Raspberry Pi touch builds
7inch HDMI LCD	7"	1024×600	Resistive (SPI)	IPS	HDMI	No	Mid-size dashboards and HMIs
10.1inch HDMI LCD	10.1"	1024×600	Resistive (SPI)	IPS	HDMI	No	Large HMIs and workbench displays
7inch HDMI LCD (H) with Case ← this model	7"	1024×600	Capacitive, 5-point (USB)	IPS	HDMI / VGA	Yes	Ready-to-deploy kiosk and desktop use
10.1inch HDMI LCD (B) with Case	10.1"	1280×800	Capacitive, 10-point (USB)	IPS	HDMI	Yes	Higher-res touch dashboards
13.3inch HDMI LCD (H) (with case) V2	13.3"	1920×1080	Capacitive, 10-point (USB)	IPS	HDMI / VGA	Yes	Premium Full HD touch displays
15.6inch HDMI LCD (H) with Case	15.6"	1920×1080	Capacitive, 10-point (USB)	IPS	HDMI / VGA	Yes	Large premium touch screens
11.9inch HDMI LCD	11.9"	320×1480	Capacitive, 5-point (USB)	IPS	HDMI	No	Portrait dashboards and side screens

Technical specifications

Screen Size	7"
Resolution	1024×600
Display Interface	HDMI / VGA
Display Panel	IPS
Viewing Angle	170°
Touch Type	Capacitive
Touch Points	5-point
Touch Interface	USB
Touch Panel	Toughened glass
Enclosure	Polycarbonate case
Audio Output	3.5mm jack
Best Fit	Finished Raspberry Pi displays, kiosks, dashboards, client demos
System Support	Raspberry Pi OS / Ubuntu / Kali / Retropie; Jetson Nano / TX2 / Xavier NX / Orin; Windows 11/10/8.1/8/7

Official Waveshare resources

Official product page
Official wiki / setup guide

Frequently Asked Questions

Does this work with Raspberry Pi? Yes. Official Waveshare resources list Raspberry Pi support for this model.

How is touch connected? This model uses Capacitive, 5-point (USB).

Can I use it with a PC? Yes. Official Waveshare documentation lists PC support for this model. Touch behavior can vary by operating system, so check the official wiki for setup notes.

Does it include a case? Yes. This model includes a case.

7inch Capacitive Touch Screen LCD (H) with Case, 1024×600, HDMI, IPS, Various Systems Support

Name: 7inch Capacitive Touch Screen LCD (H) with Case, 1024×600, HDMI, IPS, Various Systems Support
Brand: Circuitrocks
SKU: 13857
Price: 5669.0 PHP
Availability: InStock
