If you're looking for a simple battery protection board for your project, here's one for you. This board is based on the BM3451 chip. It handles 5 18650 battery in series or a total of 18.5V. It also has external bleeding for cell-capacity preservation. This prevents pressure on an individual cell leading to a longer battery lifespan.
Features:
- Suitable battery: 3.7V 18650 Lithium battery or polymer battery
- Charging Voltage: DC21V CC/CV
- Instantaneous current: 15A±2A
- Continuous current: ≤10A
- Charging current: ≤5A
- Overcharge detection: 4.25±0.025V
- Overcharge recovery: 4.15V±0.025V
- Over discharge detection: 2.8V±0.05V
- Over discharge recovery: 3.0V
- Resistance: less than 20mΩ
- Short circuit protection: protect and automatic recovery
- Recovery mode: Automatic recovery
- Size: 53mm x 18mm x 4mm
Manila stock. Order before 16:00 PHT, ships today via J&T or LBC. Provincial: 1–3 working days.
Schools / class POs: we accept Purchase Orders for accredited schools and universities. contact us with your PO details.
Returns: 7-day inspection window for DOA units. Email proof of issue and we ship a replacement.
