This Clicky Mechanical Push Button Switch delivers a clean tactile click feedback with every press, making it perfect for reliable input detection in your electronics projects. Designed as a momentary (normally open) switch, it only completes the circuit while being pressed — ideal for Arduino, Raspberry Pi, ESP32, and other microcontrollers.

Whether you’re building a custom control panel, prototype, reset/input button, or interactive DIY gadget, this switch offers precise responsiveness, easy installation, and compact size.

Specifications

• Product Type: Mechanical Keyboard Switch
• Switch Style: Clicky (Blue Stem)
• Actuation Type: Momentary (Normally Open)
• Stem Type: MX Cross (+)
• Housing Material: Transparent Plastic
• Stem Color: Blue
• Mount Type: PCB Mount
• Electrical Pins: 2 Pins
• Support Pins: 3-Pin (Plate Mount style)
• Rated Voltage: Up to 12V DC
• Rated Current: 10–50 mA
• Actuation Force: ~50–60 g
• Actuation Point: ~2.2 mm
• Total Travel Distance: ~4.0 mm
• Lifespan: Up to 10–50 million keystrokes
• Compatibility: Arduino, ESP32, Raspberry Pi, Mechanical Keyboards

Physical Dimensions

• Switch Body Size: 14 mm × 14 mm
• Body Height: ~15.6 mm
• Total Height (with pins): ~18.5 mm
• Stem Height: ~4.0 mm
• Pin Spacing (Electrical): ~5.0 mm
